Manifold questions and advice please

[biggus caine]

I'm after some advice please, i've recently bought an evo 4 and need to know the following:

the sas / egr pipe has been removed from my car, does this need to be capped off ?



The manifold has some hairline cracks in it, is this scrap or can it be welded up ?
If it is welded should I get some reinforcing webs put on it at the same time ?







I need to replace the manifold to turbo gasket where is been blowing, what type of gasket would you gents recommend for both the manifold / turbo and the manifold / head ?
The ones that came off the car were multilayer gaskets.





Any help and advice would be much appreciated. Thanks



[ad-p]

Hi mate, has the SAS valve had the vacuum line detached? If it has you shouldn't have a problem as it won't be operating, as for the manifold I would just get rid and put a standard back on much more reliable and get a gasket from dave at ears motorsport they do all the genuine mitsi stuff



[RsvRob]

Fit std manifold.
Std metal gaskets from many stockists of evo parts.
You can remove that complete SAS valve if you want. 2 bolts under it but leave the actual bracket. Any pipes should be blocked of...

Yoda



[JakeMac]

+1 to the replys above.

I had exactly the same mani on mine when I got it, that had holes in it and was blowing through the gaskets. First thing I did was put the standard back on and have never looked back



[DDS789]

Jesus that mani is shocking!

Those pics need to be used as a reason not to buy the cheapo eBay manifolds.


As said get a solid standard one on and you'll be fine

Removal of the SAS will mean no pops and bangs can be mapped onto your car.



[RsvRob]

Removal of the SAS will mean no pops and bangs can be mapped onto your car.

That's not actually true. You map the pops/bangs on the ecu.
The SAS aids in the final process. But you can get pops/bangs without it fitted



[DDS789]

That's not actually true. You map the pops/bangs on the ecu.
The SAS aids in the final process. But you can get pops/bangs without it fitted

Oooo that's good to know :thinking: is there any benefit in removing it?



[biggus caine]

thanks for the reply's and help gents.

i always thought the aftermarket manifolds helped the cars performance, is this true or myth?



[JakeMac]

thanks for the reply's and help gents.

i always thought the aftermarket manifolds helped the cars performance, is this true or myth?

They do a bit, but you get what you pay for and those japspeed ones are extramly cheap when compare to the others that are £500 upwards



[biggus caine]

that is very true fella



[invisible]

The standard manifold is good for 400/400 so unless you pushing really big power the standard manifold is fine.

I have a non-SAS manifold lying around in the shed which I bought from JapDNA but didnt use in the end as I wanted the standard SAS version.

Although not 100% sure if it will fit a 4 as it was supposed to be for a 9 when I bought it?

Btw mine had a chocolate ebay cheap tubular mani on it too that had split in several places and replaced that with standard one, does the jon perfect
